CARGO

• Especially suitable for standard Euro, British or US pallets.
• Typical penetration: 35 mm of steel.
• HI-MAT Plus technology for advanced material distinction.
• Tunnel size: 1450 mm x 1800 mm;
• Anode voltage: 160 kV;

Options: HI-TIP, HI-SPOT, SEN, XPlore, IMS, Media Bay to RIDA, HDA.
2 or 5 ton roller tables.

• Especially suitable for standard Euro, British or US pallets.
• Dual View system.
• Conveyor load: 5 tons.
• Typical penetration: 58 mm steel.
• Meets TSA requirements for skid size 1,2 m x 1,2 m x 1,65 m.
• Tunnel size: 1450 mm x 1800 mm;
• Anode voltage: 200 kV;

Options: HI-TIP, HI-SPOT, SEN, XPlore, IMS, Media Bay to RIDA, HDA.
5 ton roller tables.

• It permits the inspection of pallets and LD-3 airfreight containers.
• Dual View system.
• Typical penetration 75 mm of steel.
• Typical wire resolution AWG 37
• HI-MAT Plus technology for advanced material distinction.
• Compact footprint minimizes required floor space
• Tunnel size: 1800 mm x 1800 mm;
• Anode voltage: 300 kV;

Options: HI-TIP, HI-SPOT, SEN, XPlore, IMS, Media Bay to RIDA, HDA.
5 ton roller tables.
